| DN mm | THREAD | D mm | EC mm | B mm | NO. OF BOLTS | BOLT | D2 mm | WEIGHT kg | ITEM NO. |
|---|---|---|---|---|---|---|---|---|---|
| 15 | 1 / 2 " | 95 | 65 | 14 | 4 | M12 | 14 | 0,6 | 1250219 |
| 20 | 3 / 4 " | 105 | 75 | 16 | 4 | M12 | 14 | 0,9 | 1250224 |
| 25 | 1 " | 115 | 85 | 16 | 4 | M12 | 14 | 1,1 | 1250229 |
| 32 | 1 1/4 " | 140 | 100 | 16 | 4 | M16 | 18 | 1,6 | 1250234 |
| 40 | 1 1/2 " | 150 | 110 | 16 | 4 | M16 | 18 | 1,8 | 1250239 |
| 50 | 2 " | 165 | 125 | 18 | 4 | M16 | 18 | 2,4 | 1250244 |
| 65 | 2 1/2 " | 185 | 145 | 18 | 4 | M16 | 18 | 3,2 | 1250249 |
| 80 | 3 " | 200 | 160 | 20 | 8 | M16 | 18 | 4,1 | 1250254 |
| 100 | 4 " | 220 | 180 | 20 | 8 | M16 | 18 | 4,5 | 1250259 |
